Panel Dividing SAW MJB1328B
-
The saw car is driven by a servo motor and a rack and pinion drive, which runs smoothly.
-
Equipped with 9 clamps, large cross-section formed aluminum material, precise positioning for grabbing and pushing materials.
-
Equipped with side lean device, narrow and long board positioning is more accurate.
-
+91 99803 91827+91 99803 91827
-
info@nanxingindia.cominfo@nanxingindia.com
Technical Data
Model | NP330FG |
Cutting length | 3200mm |
Cutting thickness | 90mm |
Main saw rotating speed | 3910rpm |
Scoring saw rotating speed | 4300rpm |
Saw carriage forward speed |
90 m/min |
Saw carriage backward speed | 120 m/min |
Main saw motor | 15kw |
Auto feeding speed | 85 m/min |
Dust extraction | φ150mm×3 |
Total power | 26kw |
Overall size | 7500×5400×1810mm |
